Stec Standard Bucket DB GP
The Standard Bucket Stec DB GP is a durable 4-tooth attachment for excavators and backhoe loaders.
Apraksts
General Purpose, or GP series, digging bucket is designed for normal excavation work under normal conditions. Buckets are suitable for moving medium-abrasive material such as sand, gravel, limestone, etc. Bucket wear parts – front blade, side blades, and bucket strips are made of materials with wear resistance of HB400.
Prices: starting from EUR2,950. Please note that prices are shown without tax. Contact us for pricing options.
Stec Standard Bucket DB GP: Technical Specifications
| Specification | Details |
|---|---|
| Type | Standard |
| Load-bearing | For excavators, for backhoe loaders |
| Number of teeth | 4 teeth |
| Cutting edge / teeth type | Welded |
| Cutting edge / teeth hardness | HB500, HB400 |
| Other characteristics | For mining |
| Carrier weight | Max: 40,000 kg (88,185 lb) Min: 7,000 kg (15,432 lb) |
| Bucket width | Max: 1,700 mm (67 in) Min: 800 mm (31 in) |
| Capacity | Max: 2,200 l (581.18 gal) Min: 500 l (132.09 gal) |
| Bucket weight | Max: 2,400 kg (5,291.09 lb) Min: 300 kg (661.39 lb) |
| Bucket depth | Max: 1,880 mm (74 in) Min: 1,420 mm (56 in) |
| Bucket height | Max: 1,160 mm (46 in) Min: 875 mm (34 in) |
