Stec Standard Tooth Bucket DB HD
The Standard Bucket Stec DB HD is a robust attachment with 4 teeth, designed for excavators and backhoe loaders.
Apraksts
Heavy Duty, or HD series digging bucket is designed for tough working conditions. Buckets are perfect for moving crushed, blasted, natural abrasive material. The HD series uses HB500 wear-resistant materials. The edges of the bottom plate are also reinforced. Additional reinforcements can be added to the HD bucket series at the customer’s request – bi-Metall plates, heels, front blade protection, etc.
Prices: starting from EUR3,210. Please note that prices are shown without tax. Contact us for pricing options.
Stec Standard Bucket DB HD: Technical Specifications
| Specification | Details |
|---|---|
| Type | Standard tooth |
| Load-bearing | For excavators, for backhoe loaders |
| Number of teeth | 4 teeth |
| Cutting edge / teeth type | Welded |
| Cutting edge / teeth hardness | HB500 |
| Other characteristics | For mining |
| Carrier weight | Max: 45,000 kg (99,208 lb) Min: 5,000 kg (11,023 lb) |
| Bucket width | Max: 1,680 mm (66 in) Min: 800 mm (31 in) |
| Capacity | Max: 2.2 m³ (77.69 ft³) Min: 0.5 m³ (17.66 ft³) |
| Bucket weight | Max: 4,000 kg (8,818.49 lb) Min: 300 kg (661.39 lb) |
| Bucket depth | Max: 1,880 mm (74 in) Min: 1,420 mm (56 in) |
| Bucket height | Max: 1,160 mm (46 in) Min: 875 mm (34 in) |
